Chapter 4. Printing Data
60 DigitalFlow™ GF868 Programming Manual (1-Channel)
4.2 Print Live Data
Use the DATA submenu to print live measurement data, as it is collected. The data may be printed in either numeric or
graphical format, with a user specified time increment.
IMPORTANT: Make sure that a printer has been properly set up before proceeding with this section.
To print live measurement data, refer to Figure 15 on page 91, and complete the following steps:
1. To access the Print Menu, press the [PRNT] key.
Note: The Print Menu is not protected by the security feature and a password is never required to access this menu.
2. Press [F1] to select the DATA option.
3. Press [F1] = NUM to print the data in numeric format or press [F2] = PLOT to print the data in graphical format.
• If you press [F1], go to step 4.
• If you press [F2], go to step 8.
4.2.1 Numeric Format
4. Use the [, [ and [F1]-[F4] keys to select the first parameter to be printed. See Table 14 for a list of the available
options.
Refer to Chapter 3, Diagnostics, of the Service Manual for a discussion of the many parameters accessible using the
DIAG option.
Note: The units assigned to the parameters in Table 14 are those selected in the User Program (SYSTM submenu).
Table 14: Measurement Parameter Options
Option Bar Choice Description
[F1] = VEL Flow Velocity
[F2] = VOLUM Volumetric Flow
[F3] = +TOTL Forward Totalized Volume Flow
[F4] = -TOTL Reverse Totalized Volume Flow
[
+ [F1] = MDOT Mass Flow
[
+ [F2] = +MASS Forward Totalized Mass Flow
[
+ [F3] = -MASS Reverse Totalized Mass Flow
[
+ [F4] = DIAG Diagnostic
