2.2.4 IVUS Room Layout
2.2.4.1 IVUS Rev 2 and Rev 2+
Illustration 2-60:
NOTE: (For OR Table) the CONTROL STATION shall be installed on a cart.
2.2.4.2 IVUS Rev 3
Refer to Volcano s5i Imaging System Integration in IGS Systems - Service Manual.
Innova
TM
IGS 520, Innova
TM
IGS 530, Innova
TM
IGS 540 Pre-Installation Manual
Direction 5499972-1-1EN, Revision 2
120 2 Room Layouts
