PRODUCT OR
COMPONENT
NET WEIGHT
KG (LBS)
DIMENSIONS MM (INCHES) LOAD BEAR‐
ING AREA MM
(INCHES)
WEIGHT/
OCCUPIED
AREA
MOUNTING METH‐
OD
WIDTH DEPTH HEIGHT
Control Station 3.6 (7.9) 330 (12.99) 177 (6.97) 100 (3.94)
330 x 177
(12.9 x 6.97)
0.6 kg/m
2
On desk or rail
Joystick 0.5 (1.1) 90 (3.54) 76 (2.99) 102 (4.02) N/A N/A On rail
Touchpad control‐
ler
1 (2.2) 211 (8.31) 180 (7.09) 76 (2.99) N/A N/A On rail
Isolation trans‐
former
6 (13.2) 165 (6.50)
267
(10.51)
89 (3.50)
165 x 267
(6.50 x 10.51)
1.4 kg/m
2
On floor
S5I GE CPU 18 (39.7) 522 (20.55) 176 (6.93) 430 (16.93)
176 x 522
(6.93 x 20.55)
2.0 kg/m
2
On floor
S5I GE Keyb. &
mouse pad
1 (2.2) N/A N/A N/A N/A N/A On desk
S5I GE monitor 9 (19.8) 330 (12.99) 247 (9.72) 596 (23.46)
330 x 247
(12.99 x 9.72)
1.1 kg/m
2
On desk
Image printer 6 (13.2) 158 (6.22) 184 (7.24) 180 (7.09)
158 x 184
(6.22 x 7.24)
2.1 kg/m
2
On desk
Printer HP 1.3 (2.9) 227 (8.94) 138 (5.43) 117 (4.61)
227 x 138
(8.94 x 5.43)
0.4 kg/m
2
On desk
4-way Video
Switch
1 (2.2) 220 (8.66) 241 (9.49) 44 (1.73)
220 x 241
(8.66 x 9.49)
0.2 kg/m
2
On desk
IVUS Rev 3 Option
Refer to Volcano s5i Imaging System Integration in IGS Systems - Service Manual
NOTE: (1) including patient weight (patient weight considered is 204 Kgs/450 lbs).
NOTE:
(2) Depth.
NOTE:
(3) Maximum dimensions given. Exact dimensions depend on chiller manufacturer
type.
NOTE: (4) Recommended supplier.
NOTE: (5) The total weight (Large Display monitor suspension boom (spring arm), frame,
precabled, bridge, rails monitors (LDM + 2 B/W) and accessories) is calculated as
follows:
110 kg (frame+arm+monitors max load) + 50 kg (internal cabling) + 31 kg (bridge
plate + main bearing + connection box) + 102 kg (XT long bridge) + 63 kg (2
stationary rails 19") = 356 kg (784 lbs)
NOTE: (6) Vivid E9 weight and dimensions include monitor and peripherals.
3.3.2 Positioner and Table Floor Mounting
The distances between the Gantry and the Tables are critical for a proper clinical usage. For
this reason, GEMS provides two floor mounting templates to ensure these components are
properly placed in relation to one another.
Innova
TM
IGS 520, Innova
TM
IGS 530, Innova
TM
IGS 540 Pre-Installation Manual
Direction 5499972-1-1EN, Revision 2
140 3 Room Structural Requirements
