D
IRECTION 5305880-100, REVISION 3 LOGIQ™ 100 PRO SERVICE MANUAL
Chapter 7 - Diagnostics/Troubleshooting Page 7-13
Monitor Test (Contd.,)
Note: The patterns in 7-7 to 7-10 are written on the overlay where as the pattern in 7-11 to 7-13 is written
on the image memory.
7-7 to 7-9 are also available in reverse video
7-2-5 Key Operation History
When this option is selected from the Main Menu the following appears indicating a maximum of 32
keys last activated. The history of keys used is stored even after powered off.
Figure 7-13 Monitor Test
Figure 7-14 Key Operation History
KEY OPERATION HISTORY
KEY OPERATED KEY OPERATED
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
29.
30
31.
32.
PRESS EXT_VIDEO TO QUIT
State: RELEASE - Document is released and under formal Change Control. Changes are subject to the ECR/ECO Process. See the GEHC Myworkshop System to determine the status of this document.
Approved Document - 5305880-100TPH_r3.pdf Page 118 of 197
