GE HEALTHCARE
D
IRECTION 5305880-100, REVISION 3 LOGIQ™ 100 PRO SERVICE MANUAL
Page 3-20 Section 3-6 - System Configuration
SIDE VIEW
3-6-1-5 Weight without Peripherals
The Weight of LOGIQ™ 100 PRO without peripherals
3-6-2 Electrical Specifications
Electrical Specifications for LOGIQ™ 100 PRO.
Model Weight [kg]
LOGIQ™ 100 PRO 9.00
Table 3-4 Weight of LOGIQ™ 100 PRO
GEMS
HCAT NUMBER
Voltage Tolerance
s
Current Frequency
H41072LA,H41072LB,
H41072LC,H41072LD,
H41072LE,H41072LF,
H41072LS
100-230 VAC ±10% 0.9 -1.8 A Max. 50-60 Hz
Table 3-5 Electrical Specifications for LOGIQ™ 100 PRO
State: RELEASE - Document is released and under formal Change Control. Changes are subject to the ECR/ECO Process.
See the GEHC Myworkshop System to determine the status of this document.
Approved Document - 5305880-100TPH_r3.pdf Page 65 of 197
