Page 8-12 Section 8-4 - FRONT PANEL/MONITOR
8-4-2 Disassembly/Assembly of Monitor
Follow steps below and refer Figure 8-7. For FRU Details refer 9-1-6
1.) Remove Top Cover. Refer 8-2
2.) Remove Front Panel. Refer 8-4-1
3.) Disconnect the communication cables between the Analog and Digital circuits.
4.) Remove Shield Plate.
5.) Remove the communication cable - VIDEO IN (b), Brightness/Contrast (i,j) and the power
cable (a) on the CRT PCB.
6.) Remove the 2 screws (c,d) holding the CRT drive PCB to the chassis.
7.) Remove 4 screws (e,f,g,h) holding the CRT Assy connected to the chassis.
8.) Move the CRT forward along with CRT driver PCB assembly.
9.) For assembly follow the reverse order.
Note: Ensure that the monitor switch (all the four) near Fly Back Transformer is set to PAL side in case of
PAL systems and to NTSC side in case of NTSC systems.
Note: If CRT fails replace along with PCB
Table 8-6 Functional tests
Service Manual
Section
Functional Test/ Diagnostic Test Debrief Script
4-2-1 Power ON/ Boot up
Service manual direction 5305880-
100, Section 8-4-2.Equipment
passed all required tests and is
ready for use.
4-2-1 Power OFF/ Shut down
4-3 Functional Checks
7-2-4 Diagnostics tests
