GE HEALTHCARE
D
IRECTION 5305880-100, REVISION 3 LOGIQ™ 100 PRO SERVICE MANUAL
Chapter 3 - Installation Page 3-17
3-5-5 Adjustment of Monitor Brightness & Contrast
Turn ON the Machine and then adjust the monitor contrast and brightness. Monitor contrast and
brightness should be adjusted according to the lighting in the room. For Monitor brightness and
contrast adjustment refer to the appropriate section in the User Manual.
3-5-6 Adjustment of System Clock/Date, Hospital Name & OB Version
Press CTRL-S-1 ENTER, an `Installation Setup window appears'. Set the system Clock/Date,
Hospital Name and OB Version. These settings can be modified by using the CONTROL-S-1 key if
required. Refer Section Control Keys of the User Manual for more details
CAUTION Functional checks in Chapter 4, to be carried out before handing over the system to the
customer
Section 3-6 System Configuration
3-6-1 System Specifications
3-6-1-1 Physical Dimensions
The physical dimensions of the LOGIQ™ 100 PRO unit are summarized in Table 3-2.
Height Width Depth
Unit
28.9 30.24 42.06
cm
Table 3-3 Physical Dimensions of LOGIQ™ 100 PRO
State: RELEASE - Document is released and under formal Change Control. Changes are subject to the ECR/ECO Process.
See the GEHC Myworkshop System to determine the status of this document.
Approved Document - 5305880-100TPH_r3.pdf Page 62 of 197
