GE HEALTHCARE
D
IRECTION 5305880-100, REVISION 3 LOGIQ™ 100 PRO SERVICE MANUAL
Page 4-10 Section 4-6 - Peripheral Checks
Section 4-5 Software Configuration Checks
Section 4-6 Peripheral Checks
Check that peripherals work as described below:.
Step Check Expected Result(s) If Not Remedy
1. Check Date and Time setting Date and Time are correct Adjust the Date and Time setting
2. Check that Location (Hospital Name) is
correct
Location Name is correct Re-enter the correct Location Name
Table 4-3 Software Configuration Checks
Step Check Expected Result(s) If Not Remedy
1. Press Freeze Key To stop image acquisition.
2. Press RECORD Key on the Control
panel
The image displayed on the screen is
printed on B&W Video Graphic Printer.
3. Press SHIFT + RECORD Key on the
Control Panel.
To image or report page displayed on
the screen is printed on the Laser Jet
Printer connected to the USB Port of
the System.
4. Press SHIFT + RECORD Key on the
Control Panel.
To print the displayed image on the
screen to the USB B&W Video Graphic
Printer.
5. Press EXTERNAL VIDEO Key on the
Control Panel
Enables an External Video Input
Playback on the LOGIQ™ 100 PRO
monitor. Press once again to return to
the scan mode
Table 4-4 Peripheral checks
State: RELEASE - Document is released and under formal Change Control. Changes are subject to the ECR/ECO Process.
See the GEHC Myworkshop System to determine the status of this document.
Approved Document - 5305880-100TPH_r3.pdf Page 85 of 197
