IRECTION 5305880-100, REVISION 3 LOGIQ™ 100 PRO SERVICE MANUAL
Chapter 3 - Installation Page 3-19
3-6-1-3 Side View (Keyboard Closed)
3-6-1-4 Side View (Keyboard Open)
Figure 3-15 Side View (Keyboard Closed)
420.6 (16.5)
405 (15 9)
Figure 3-16 Side View (Keyboard Open)
596
(
23.5
)
289 (11.4)
