GE HEALTHCARE
D
IRECTION 5305880-100, REVISION 3 LOGIQ™ 100 PRO SERVICE MANUAL
Page 9-14 Section 9-1 - Overview
9-1-12 MATERIAL LIST - Cable Assembly
OPERATOR CONSOLE ASSY
5304117,5304414,5304240,5304248,5304441,5304596,5306834.
LOGIQ™ 100 PRO Cable Set comprises of:
List of PROBES
*To be used along with L200 probe Adapter.
FRU No. PART NAME PART NO. QTY FRU DESCRIPTION
1301 LOGIQ™ 100 PRO Cable Set 5308178 1 1 For LOGIQ™ 100 PRO
Table 9-2 Cable Assembly for LOGIQ™ 100 PRO
Part Name Part Number QTY. Description
Cable Assy 3N 5268930 1 Cable used for interfacing mains power, low voltage power supply, noise filter and
power switch Contains, apart from cable, Core Support Clamp and associated Screws
and Nuts
USB Cable
Assy
5269617 1 Davinci - Rear Panel USB Port cable for LOGIQ™ 100 PRO.
Cable Assy 28N 5267859 1 Power Distributor (PDB) to FEB
Cable Assy 29N 5265017 1 Power Supply to Power Distributor (PDB)
Cable Assy 30N 5273256 1 FEB to HV Power Supply
Table 9-3 Cable Set for LOGIQ™ 100 PRO.
Probe
Type
Part No. Catalog No.
C36 2268634 H41252CF
C55 2107925 H45252CE
E72 2274908 H41252ME
L76 2274906 H41252HP
C31 2175994 H45252CS
*CZB 2152422 H45202CZ
*LB P9601AQ H46022LB
State: RELEASE - Document is released and under formal Change Control. Changes are subject to the ECR/ECO Process.
See the GEHC Myworkshop System to determine the status of this document.
Approved Document - 5305880-100TPH_r3.pdf Page 169 of 197
