IRECTION 5305880-100, REVISION 3 LOGIQ™ 100 PRO SERVICE MANUAL
Chapter 1 - Introduction Page 1-7
"CAUTION" The equilateral
triangle is usually used in
combination with other
symbols to advise or warn the
user.
Various
ATTENTION - Consult
accompanying documents " is
intended to alert the user to
refer to the operator manual or
other instructions when
complete information cannot
be provided on the label.
Various
"CAUTION - Dangerous
voltage" (the lightning flash
with arrowhead in equilateral
triangle) is used to indicate
electric shock hazards.
Various
"Mains OFF" Indicates the
power off position of the mains
power switch.
Rear of system adjacent to
mains switch
"OFF/Standby" Indicates the
power off/standby position of
the power switch.
CAUTION
This Power Switch DOES
NOT ISOLATE Mains
Supply
Adjacent to On-Off/Standby
Switch
"Mains ON" Indicates the
power on position of the mains
power switch.
"ON" Indicates the power on
position of the power switch.
CAUTION
This Power Switch DOES
NOT ISOLATE Mains
Supply
"Protective Earth" Indicates
the protective earth
(grounding) terminal.
LABEL/SYMBOL PURPOSE/MEANING LOCATION
Table 1-5 Product Icons
