GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
Chapter 4 Functional Checks 4 - 17
4-2-11 Recording important settings and parameters
4-2-11-1 Overview
See the following pages to record data.
These subsections include descriptions for recording/setting up data for the following screens.
With the system Powered On, follow the procedures below to document basic system information and
back up Presets, and if required, Patient Archive and Patient Images prior to software load.
• Utility -> Connectivity
-TCP/IP (see: 4-2-11-2 "Connectivity — Recording the TCP/IP settings" on page 4-18)
- Device (see: 4-2-11-4 "Connectivity — Recording the AE Title and Port settings" on page 4-
20)
- Misc (see: 4-2-11-8 "Connectivity — Recording Miscellaneous settings" on page 4-24)
• Utility -> Admin
- System Admin (see: 4-2-11-9 "Admin — Recording the Software Option Keys" on page 4-26
These subsections include descriptions for recording/setting up data for the following screens.
Hardcopy forms are provided here for convenience, but content will be included if selected during
Backup process.
• Utility -> Connectivity
- 4-2-11-5 "Connectivity — Recording Device Destination settings" on page 4-21Service (see:
4-2-11-5 "Connectivity — Recording Device Destination settings" on page 4-21).
- Dataflow (see: 4-2-11-6 "Connectivity — Recording Dataflow settings" on page 4-22).
- Buttons (see: 4-2-11-7 "Connectivity — Recording the Print Key Assignments" on page 4-23).
- Removable Media (see: 4-2-11-6 "Connectivity — Recording Dataflow settings" on page 4-
22).
• Utility -> Admin
- Users (see: 4-2-11-10 "Admin — Users" on page 4-27)
• Utility -> System
- Backup/Restore (see: 4-2-11-11 "System — Data Store Management" on page 4-28).
- Peripherals (see: 4-2-11-12 "System — Recording Peripheral settings" on page 4-29).
- About (see: 4-2-11-13 "System — Recording software and hardware versions" on page 4-30).
- General, Record Region, Language and Regional Options. See the latest revision of the
LOGIQ E9 Basic User Manual, Chapter 16.
An error or power loss may occur during the software loading.
Always keep a paper record of the settings for the LOGIQ E9. Verify that it is current before starting a
software load!
To Next Page
