GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
4 - 16 Section 4-2 - General procedures
4-2-10-3 To ensure safety while moving the LOGIQ E9
1.) Ensure that the keyboard console and LCD monitor are in locked position (see: 4-2-4 "Top Console
position adjustment" on page 4-10 and 4-2-5 "LCD Monitor Positions and Lock" on page 4-11).
2.) Proceed cautiously when crossing door or elevator thresholds. Grasp the front handle grips or the
back handle bar and push or pull. Do not attempt to move the LOGIQ E9 using cables or probe
connectors. Take extra care while moving the LOGIQ E9 on inclines.
3.) Ensure that the LOGIQ E9 does not strike the walls or door frames.
4.) Ensure that the pathway is clear.
5.) Move the LOGIQ E9 slowly and carefully.
6.) Use two or more persons to move the LOGIQ E9 over long distances or on inclines.
4-2-10-4 Transporting the LOGIQ E9 by vehicle
Take extra care when transporting the LOGIQ E9 by vehicle. In addition to the moving precautions listed
on 4-2-10-3 "To ensure safety while moving the LOGIQ E9" on page 4-16‘, follow the procedure
described below.
1.) If not locked, move the keyboard console and LCD monitor to the park position (see: 4-2-4 "Top
Console position adjustment" on page 4-10 and 4-2-5 "LCD Monitor Positions and Lock" on page
4-11).
2.) Disconnect all probes and secure them in their boxes.
3.) Ensure that the transporting vehicle is appropriate for the unit’s weight.
4.) Park the vehicle on a level surface for loading and unloading.
5.) Secure the unit while it is on the lift, to prevent rolling. Do not attempt to hold it in place by hand.
Cushion the unit and strap the lower part so that it does not break loose.
6.) Ensure that the unit is secured inside the vehicle. Secure it with straps to the two hooks under the
system to prevent movement while in transit.
7.) Drive cautiously to prevent vibration damage.
4-2-10-5 Setting up at a new location
1.) When the unit is in place at a new location, lock the wheel brakes.
2.) Follow the set up procedure described in Section 3-6 "Completing the setup" on page 3-16.
Do not move the LOGIQ E9 if the keyboard console and LCD Monitor are in free position.
Ensure that the hands of the patient and user are away from the console arm when
moving the keyboard console.
Avoid ramps that are steeper than 10 degrees.
Do not move/lift the unit if the keyboard console and LCD monitor are in free (unlocked)
position.
