GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
4 - 22 Section 4-2 - General procedures
4-2-11-6 Connectivity — Recording Dataflow settings
1.) From the Touch Panel, select Utility -> Connectivity -> Dataflow.
2.) Record all settings in Table 4-7 "Record settings from Service screen" on page 4-22.
Figure 4-16 Dataflow settings
Table 4-7 Record settings from Service screen
DESTINATION DEVICE
NAME
SERVICES (TYPES) FOR EACH
DESTINATION DEVICE
PROPERTIES NAME
