IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
Chapter 1 Introduction 1 - 9
DEFIBRILLATOR-PROOF TYPE CF
EQUIPMENT.
At the ECG connector on front of
system.
Device Listing/Certification Labels
Laboratory logo or labels denoting
conformance with industry safety
standards such as UL or IEC.
Rear of console
This precaution is intended to prevent
injury that may result if one person
attempt to move the unit considerable
distances or on an incline due to the
weight of the unit.
Rear cover label
DO NOT push the system at this point or
from this area. Use the handle to push/
pull the system, e.g., DO NOT use the
LCD. Failure to do so may cause
serious injury or system damage.
Rear of LCD Monitor
Front of On-Board V Nav Stand
Follow Instructions for Use.
“ATTENTION” - Consult accompanying
documents is intended to alert the user
to refer to the operator manual or other
instructions when complete information
cannot be provided on the label.
Rear Cover,
Rear of LCD Monitor,
Miscellaneous Probe Labels
Follow Instructions for Use.
“ATTENTION” - Consult accompanying
documents is intended to alert the user
to refer to the operator manual or other
instructions when complete information
cannot be provided on the label.
Rear of particular Main Power Supply
“DANGER - Risk of explosion used in...”
The system is not designed for use with
flammable anesthetic gases.
Rear cover console
The system is not designed for use with
flammable anesthetic gases.
Rear of console
C-UL Mark Parts
Indicates that the product has been
tested and approved in UL Laboratories,
based on UL and CSA standards,
through mutual approval activities.
Rear of LCD Monitor (inside)
Footswitch
Table 1-6 Product icons (Continued) 2 of 7
LABEL/SYMBOL PURPOSE/MEANING LOCATION
