GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
Chapter 8 Replacement procedures 8 - 9
8-4-5 Backing up the Patient Archive and System Configurations
For information, refer to the latest revision of the LOGIQ E9 Basic User Manual, Chapter 3.
8-4-6 Loading the Software
8-4-6-1 Manpower
One person, 60 minutes.
8-4-6-2 Tools
• Software CDs
• Service Dongle
8-4-6-3 Overview
The Hard Disk Drive on LOGIQ E9 is divided into five partitions.
NOTE: The Hard Disk Drive on LOGIQ E9 has three visible partitions (two partitions are hidden).
When installing (and reinstalling) software, you get the choice to either replace all the contents on the
Hard Disk Drive, or only install the software on the C: partition. If you chose to replace all the contents
on the Hard Disk Drive, all stored data, including all set-up data will be lost. It is considered to be the
best practice to always move images away from the Hard Disk Drive, do backup of databases etc. and
record important configuration data on paper before starting a software load or reload, as described
earlier in this section.
The software is delivered on two CDs, one for the system software (which is technically a DVD) and one
for the LOGIQ E9 application software. In some cases, a third CD with a software patch, may also be
included. A software patch CD is used when a few new files should be installed or changed, but the
changes do not require a complete software load.
When installing the software, start with the system software, then the application software and if
included, install the patch software at the end. This is described in detail over the next pages.
Table 8-3 Use of the Partitions
DRIVE LETTER LABEL
C: SYSTEM
D: USER
E: ARCHIVE
To Next Page
