Chapter 8 Replacement procedures 8 - 61
8-5-13 Cable Hook replacement
8-5-13-1 Manpower
One person, 15 minutes.
8-5-13-2 Tools
For tools needed, refer to: 8-2-5 "Tools needed for servicing the LOGIQ E9" on page 8-5.
8-5-13-3 Preparations
When preparing for the replacement, you must perform the following steps:
1.) Power down the system
2.) Disconnect the mains power cable from the wall outlet.
3.) Remove the Side Covers.
4.) Remove the Rear Cover.
Follow these links if you need more information:
• 4-2-3 "Power shut down" on page 4-7.
• 8-5-2 "Side Covers replacement" on page 8-30.
• 8-5-11 "Rear Cover replacement" on page 8-54.
8-5-13-4 Cable Hook removal
1.) Locate the Cable Hook(s).
2.) Place the Rear Cover face down on a protected, flat surface.
3.) Remove the screw securing the Cable Hook.
4.) Repeat step 2 to remove the other Cable Hook, if necessary.
Figure 8-25 Cable Hooks

GE LOGIQ E9 Specifications

General

Type	Ultrasound System
3D/4D Imaging	Yes
Transducer Ports	4 active ports
Connectivity	DICOM, USB, Ethernet
Applications	Abdominal, Vascular, Musculoskeletal, Small Parts, Urology, Pediatric, Cardiac, Obstetrics/Gynecology
Transducers	Linear, Convex, Phased Array, Volume
Doppler Modes	Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Elastography	Yes
Advanced Features	B-Flow, Volume Navigation
Portability	Cart-based system
Display	19-inch high-resolution LCD monitor
