GE LOGIQ E9 Service Manual

GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
1 - 18 Section 1-4 - Safety considerations
1-4-3 Mechanical safety (cont’d)
NOTE: Special care should be taken when transporting the unit in a vehicle, see 4-2-10-4 "Transporting
the LOGIQ E9 by vehicle" on page 4-16.
CAUTION
LOGIQ E9 WEIGHS 135 KG (298 LB), R3.X AND EARLIER, 140 KG (309 LB), R4.X AND
LATER, OR MORE, DEPENDING ON INSTALLED PERIPHERALS, WHEN READY FOR
USE. CARE MUST BE USED WHEN MOVING IT OR REPLACING ITS PARTS. FAILURE TO
FOLLOW THE PRECAUTIONS LISTED BELOW COULD RESULT IN INJURY,
UNCONTROLLED MOTION AND COSTLY DAMAGE. ALWAYS:
- BE SURE THE PATHWAY IS CLEAR.
- USE SLOW, CAREFUL MOTIONS.
- USE TWO PEOPLE WHEN MOVING ON INCLINES OR LIFTING MORE THAN
16 KG (35 LBS).
CAUTION
TO AVOID INJURY OR DAMAGE TO THE MONITOR, MAKE SURE THERE IS NOTHING WITHIN
RANGE OF THE LCD BEFORE MOVING THE MONITOR AND MONITOR ARM. THIS INCLUDES
PEOPLE AS WELL AS THINGS.
CAUTION
Ensure that nobody touches the console arm/frogleg when moving the Operator Panel.
CAUTION
Use Protective Glasses during drilling, filing and during all other work where eyes need
protection.
CAUTION
Use Safety Shoes when doing work where there is any chance of foot damage.
CAUTION
Use Protective Gloves when drilling and cutting.
NOTICE
Be careful not to pinch any of the cables.

GE LOGIQ E9 Specifications

General

Type	Ultrasound System
3D/4D Imaging	Yes
Transducer Ports	4 active ports
Connectivity	DICOM, USB, Ethernet
Applications	Abdominal, Vascular, Musculoskeletal, Small Parts, Urology, Pediatric, Cardiac, Obstetrics/Gynecology
Transducers	Linear, Convex, Phased Array, Volume
Doppler Modes	Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Elastography	Yes
Advanced Features	B-Flow, Volume Navigation
Portability	Cart-based system
Display	19-inch high-resolution LCD monitor
