8-5-20-6 Calibration and adjustments
No calibrations or adjustments are needed after this part replacement.
8-5-20-7 Verification
Perform the following steps to verify that the product is functioning as intended after this replacement:
1.) Verify that all screws removed earlier have been installed.
2.) If finished, connect cables and Probes removed earlier.
3.) Power up the system to verify that it operates as intended.
8-5-20-8 Functional Checks
Perform the following functional checks to confirm the system is operational before returning the system
to the customer.
Table 8-51 Covers under XY / Frogleg motors Functional Checks
See:
Section Functional Check Debrief Script
4-2-2 Power ON/Boot Up
LOGIQ E9 Service Manual, Direction
5535208-100, Rev. 2. Equipment passed all
required checks and is ready for use.
4-2-3 Power shut down
4-2-4 Top Console position adjustment
4-3-14 Probe/Connectors Checks
4-3-5 B-Mode Checks
4-3-7 System CFM and PWD Checks
4-3-18 Mechanical Function Checks
4-3-18-2 Brakes and Direction Lock Checks
