GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
8 - 162 Section 8-6 - Replacing Top Console Parts
8-6-11 Options Holder / Left or Right Support replacement
The Options Holder (the Left Support or Right Support) is the base piece that attaches to the upper
console to support either a Transvaginal Probe Holder, a Gel Warmer, or a Storage Tray. The system
can support one Left Options Holder and one Right Options Holder at the same time. A Right Options
Holder comes standard with the system, with the Gel Warmer (48V).
8-6-11-1 Manpower
One person, 15 minutes.
8-6-11-2 Tools
For tools needed, refer to: 8-2-5 "Tools needed for servicing the LOGIQ E9" on page 8-5.
8-6-11-3 Preparations
When preparing for the replacement, you must perform the following steps:
1.) Power down the system.
2.) Disconnect the mains power cable from the wall outlet.
3.) If the Options Holder is supporting the Gel Warmer, remove the Gel Warmer first (8-6-12 "Gel
Warmer replacement" on page 8-166).
4.) Separate and remove the Storage Tray or Transvaginal Probe Holder from the Options Holder, if
applicable.
Follow these links if you need more information:
• 4-2-3 "Power shut down" on page 4-7.
• 8-6-12 "Gel Warmer replacement" on page 8-166.
• 8-6-13 "Storage Tray / Transvaginal Probe Holder replacement" on page 8-170.
Energy Control and Power Lockout for LOGIQ E9
WHEN SERVICING PARTS OF THE SYSTEM WHERE THERE IS EXPOSURE TO VOLTAGE
GREATER THAN 30 VOLTS:
1. TURN OFF THE SCANNER.
2. UNPLUG THE SYSTEM.
3. MAINTAIN CONTROL OF THE SYSTEM POWER PLUG.
4. WAIT FOR AT LEAST 20 SECONDS FOR CAPACITORS TO DISCHARGE AS THERE ARE NO
TEST POINTS TO VERIFY ISOLATION. THE AMBER LIGHT ON THE OP PANEL ON/OFF BUTTON
WILL TURN OFF.
5. DISCONNECT THE EPS (EXTENDED POWER SHUTDOWN) BATTERY AT J3, OR THE
BATTERY FROM THE CHARGEBOARD AT PCN1 WHEN WORKING IN THE BEP. THIS SHOULD
BE DONE WHENEVER THE BEP IS OPEN AND THE EPS OR CHARGEBOARD IS EXPOSED AND
CHANGING PARTS.
Beware that the Main Power Supply, Extended Power Shutdown or ChargeBoard and BEP may be
energized even if the power is turned OFF if the cord is still plugged into the AC Outlet.
