GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
8 - 182 Section 8-7 - Main Console parts replacement
8-7-3-1 Removal Process with Looped Strap (cont’d)
4.) Remove the filter from the frame.
NOTE: The filter frame will clear your fingers as you remove the filter.
Figure 8-58 Filter removed
Figure 8-59 Bottom View to show Removing the Filter
Tilting the system is NOT a recommended method for the removal of the filter. The
bottom view in Figure 8-59 is only for illustrative purposes.
