GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
Chapter 8 Replacement procedures 8 - 209
8-9-3-1 BEP removal
Table 8-126 BEP removal - R4.x and later
Steps Corresponding Graphic
When you return the used BEP to your local parts organization, make sure you remove ALL
PATIENT DATA from the Hard Drive, given that the Hard Drive is still functional.
In some countries, you may be required to delete all software from the disk before returning the
BEP to the parts warehouse. Follow your local policies.
Before you dispose of the Hard Drive, make sure you remove ALL PATIENT DATA from the Hard
Drive, given that the Hard Drive is still functional.
In some countries, you may be required to delete all software from the disk before returning the
Hard Drive to the parts warehouse. Follow your local policies.
When the BEP door is open, the ChargeBoard is exposed. When working inside the BEP,
remove the battery cable from PCN1 on the ChargeBoard. Otherwise, the 24V battery will be
exposed. If you drop a tool or a screw on the Extended Power Shutdown or ChargeBoard, you
could short the battery. Permanent damage will be done if this happens.
NOTE:
You cannot power up the unit with the cables detached. The system will power up without the battery
pack, but the cables on the cover must be attached.
Some cables in the BEP have a locking latch. Make sure to slide the locking latch towards you and pull
the connector to the left to release.
1.
Disconnect all I/O cables and all cables at the top of the BEP.
2.
Loosen the thumb screws or screws at the top of the BEP cover, or the three screws that attach
the cover to the BEP.
Tilt the top of the BEP cover away from the BEP.
To Next Page
