GE LOGIQ E9 Service Manual

GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
Chapter 8 Replacement procedures 8 - 229
8-9-6-2 HDD installation
Table 8-141 HDD installation
Steps Corresponding Graphic
1.
Slide the HDD bracket hinges into the BEP frame slots.
2.
Connect the cables to the HDD.
3.
Swing the HDD bracket into place.
4.
Install the screw that secures the HDD bracket.
5.
Insert the base of the BEP cover at the base of the BEP.
Be sure the bottom lip of the BEP cover rests inside the BEP.
6.
Connect the Battery cable to J3 on the EPS and EPS to BEP cables to the EPS.
7.
Make sure all cables are clear of the BEP Cover and tilt the top of the BEP cover toward the BEP.
NOTICE
Be careful not to pinch any of the cables when installing the BEP cover.
8.
Tighten and secure the thumb screw(s) at the top of the BEP cover, or the three screws that
attach the cover to the BEP.
9.
Replace the side cover.
10.
Power up the system.
11.
Reinstall the Base Load and Application Software.
12.
Enter the TCPIP settings and Option strings for the LOGIQ E9.
13.
Restore the Patient Archive images, Report Archive, User-Defined Configuration (Customer
Presets), and Service settings.
14.
Perform Functional Checks. See: 8-9-7-3 - Calibration and adjustments,
8-9-7-4 - Verification and 8-9-7-5 "Functional Checks" on page 8-234.

GE LOGIQ E9 Specifications

General

Type	Ultrasound System
3D/4D Imaging	Yes
Transducer Ports	4 active ports
Connectivity	DICOM, USB, Ethernet
Applications	Abdominal, Vascular, Musculoskeletal, Small Parts, Urology, Pediatric, Cardiac, Obstetrics/Gynecology
Transducers	Linear, Convex, Phased Array, Volume
Doppler Modes	Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Elastography	Yes
Advanced Features	B-Flow, Volume Navigation
Portability	Cart-based system
Display	19-inch high-resolution LCD monitor
