GE LOGIQ E9 Service Manual

GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
8 - 290 Section 8-11 - Peripherals replacement
10.
Connect the Power and USB Cables to the
Printer.
11.
Any slack on the cables can be pushed in
at this point.
Secure the Rear and Top Cover. MAKE
SURE the Cables DO NOT get pinched.
Cables positioned correctly.
12.
Reinstall Side Covers.
Table 8-180 Printer Bracket installation
Steps Corresponding Graphic

GE LOGIQ E9 Specifications

General

Type	Ultrasound System
3D/4D Imaging	Yes
Transducer Ports	4 active ports
Connectivity	DICOM, USB, Ethernet
Applications	Abdominal, Vascular, Musculoskeletal, Small Parts, Urology, Pediatric, Cardiac, Obstetrics/Gynecology
Transducers	Linear, Convex, Phased Array, Volume
Doppler Modes	Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Elastography	Yes
Advanced Features	B-Flow, Volume Navigation
Portability	Cart-based system
Display	19-inch high-resolution LCD monitor
