IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
8 - 300 Section 8-12 - V Nav Roll Stand and/or On-Board Stand Installation and/or Replacement
8-12-1 Parts Reference - Roll Stand (cont’d)
The following parts and hardware are included with this installation kit (hardware not shown):
Table 8-189 Volume Navigation Roll Stand Installation Kit - Parts Reference
Item # Description Quantity
1 Roll Stand Post, 60 inches 1
2 Roll Stand Base with 21-lb. Counterweight 1
3 5/16-18 x 1 inch Hex Head Cap Screw (HHCS) 1
4 5/16 Flat Washer 1
5 5/16 Split Lock Washer 1
6 GE Volume Navigation Arm 1
7 Cord Loop Hook 1
8 Utility Basket 1
9 Handle 1
10 Track Cover, 12 inches 3
11 Cover Plate 1
not shown 1/4-20 x 3/8 inch Socket Head Cap Screw (SHCS) 4
not shown 1/2 inch Socket Wrench 1
not shown 3/16 inch Hex Wrench 1
not shown 3/32 inch Hex Wrench 1
not shown 1/8 inch Hex Wrench 1
