GE LOGIQ E9 Service Manual

GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
Chapter 9 Renewal Parts 9 - 37
Section 9-8 Top Console parts (cont’d)
Table 9-14 Upper Op Panel FRUs Compatible Configurations
Op Panel -
Upper
Assembly
LCD
Type
High Voltage
Inverter Type
Used
High Voltage Inverter
Part Number Comments
5207000-13 NEC NEC GA200442
ERG HV Inverter is not compatible
Continue using NEC HV Inverter.
5207000-23 NEC NEC GA200442
5207000-33 CMO
NEC or
ERG
GA200442
5207000-6 (recommended)
NEC HV Inverter can be used, but may show
intermittent issues turning on the back light at
boot up.
5207000-43 CMO
NEC or
ERG
GA200442
5207000-6 (recommended)
5207000-53 CMO ERG 5207000-6
Forward production all contain ERG
HV Inverters.

GE LOGIQ E9 Specifications

General

Type	Ultrasound System
3D/4D Imaging	Yes
Transducer Ports	4 active ports
Connectivity	DICOM, USB, Ethernet
Applications	Abdominal, Vascular, Musculoskeletal, Small Parts, Urology, Pediatric, Cardiac, Obstetrics/Gynecology
Transducers	Linear, Convex, Phased Array, Volume
Doppler Modes	Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Elastography	Yes
Advanced Features	B-Flow, Volume Navigation
Portability	Cart-based system
Display	19-inch high-resolution LCD monitor
