GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
Chapter 9 Renewal Parts 9 - 63
Section 9-12 Card Rack parts (cont’d)
9-12-3 GTX Boards Compatible Configuration
NOTE:It recommended to replace like for like GTX Boards. If stock of a particular board is not available, use
this table to ensure the correct combination of GTX Boards are installed in the system:
GTX "numbers" use 1, 2, 3 and 4 as nomenclature in VPD, but 0 (zero), 1, 2 and 3 are used as
nomenclature in diagnostics. In this Table, 1, 2, 3 and 4 nomenclature is used to identify board, based
on location in the Card Rack.
* If replacing P/N 5201044-2 and there is no stock, order P/N 5201044-3 and the Late Request
Plan for FMI 70206 - R2.0.4 Software Upgrade and XYZ USB Cable Update in SN70443A –
Closed FMIs on LOGIQâ„¢ E9, LOGIQâ„¢ 9 and LOGIQâ„¢ 700 Consoles.
** 5201044-3, Rev. D or later are recommended. If P/N 5201044-3 is not available, use
P/N 5201044-5.
NOTE: DO NOT mix 5201044-6 or -7 with earlier boards.
Table 9-26 GTX Boards Compatible Configurations
System configuration
GTX1
(Slot 1)
GTX1
(Slot 2)
GTX1
(Slot 3)
GTX1
(Slot 4)
Minimum
Software
Non-CW
GRX -
P/N GA200295
Not
populated
P/N 5201044-2*
R 1.0.3
R 1.0.4
R 1.0.5
P/N 5201044-2, 5201044-3**, 5201044-5 or
5201044-4
R 1.0.6
MRX -
P/N 5393908-2
P/N 5201044-3** or 5201044-5
for Shear Wave Option, all three Boards need to
be 5201044-6 or -7
R3.1.1 or later
MRX -
P/N 5393908-4
MRX -
P/N 5393908-6
R4.3.0 or later
CW
GRX -
P/N GA200105
P/N 5201044-3, 5201044-4 or 5201044-5 R2.x or later
MRX - P/N 5393908
P/N 5201044-3** or 5201044-5
for Shear Wave Option, all three Boards need to
be 5201044-6 or -7
R3.1.2 or later
MRX - P/N 5393908-5 P/N 5201044-6 or 5201044-7 R5.x.x or later
