GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
9 - 80 Section 9-15 - Peripherals
9-15-2 Digital Video Disc (DVD) Drive (cont’d)
NOTE: * FRU consists of the assembly, which includes the Drive and the metal tray. R3 version also
includes the Interface Board.
NOTE: ** Even though the Drive is compatible, manufacturing will not use this Drive on
non-DVR LOGIQ E9s.
The DVR Option (both R4 and earlier) includes a DVD Drive Assembly. This ensures that the
LOGIQ E9 receiving the DVR Option has a compatible drive to work with the DVR.
• For R4 or later, the DVR has to be activated in Windows desktop after the option is installed or after
the R4 or later Upgrade (if the DVR Option is transferred).
NOTE: Detailed information on DVR Option updates can be found in the latest revision of the
LOGIQ E9 DVR Option Installation Instructions Direction 5180205-100.
Table 9-33 DVD FRUs Description and
Part
Number
Description Comments
5305921-3
DVD Assembly, LOGIQ E9 -
DVR Compatible
Included in the DVR Option
(H4908DR - DVR Option Kit
for LOGIQ E9 running R1.0.5 through R3.x.x) -
replaces 5305921.
5305921-4
DVD Assembly, LOGIQ E9 R4 -
DVR Compatible
Included in the DVR Option
(H4913DR - DVR Option Kit for
LOGIQ E9 running R4.x.x or later) -
replaces 5305921-2.
5305921-5
DVD Assembly, LOGIQ E9 -
not DVR Compatible
Compatible for LOGIQ E9 running
R1.0.5 through R3.x.x without DVR Option -
replaces 5305921.
5305921-6
DVD Assembly, LOGIQ E9 R4 -
not DVR Compatible
Compatible for LOGIQ E9 running
R4.x.x or later without DVR Option -
replaces 5305921-2.
Table 9-34 DVD to DVR Compatibility
Manufacturing
C = compatible
N = not compatible
Service Comments
R3 R4 FRU*
Drive Type No DVR DVR No DVR DVR R3 R4 or later
Current
LG Drive
C C C C 5305921 5305921-2 This Drive is obsolete.
New LG Drive
C N C N 5305921-5 5305921-6
This Drive will be used for forward
production only for LOGIQ E9s ordered
without DVR.
Sony Drive
C** C C** C 5305921-3 5305921-4
This Drive will be used in forward
production only on orders with DVR and
DVR Option Kits.
