GE LOGIQ E9 Service Manual

GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
9 - 86 Section 9-17 - Internal Cables
9-17-2 Top Console Cables (cont’d)
Figure 9-5 Top Console cable diagram - R5.x and later
Table 9-37 Top Console cables
ITEM PART NAME PART NUMBER DESCRIPTION QTY FRU
1.
MAIN Cable Harness 5272357-2
Cable D,
• D1 - Power/Audio (BEP > Operator Panel)
• D2 - DVI Video (BEP > Operator Panel)
• D3 - XYZ (Operator Panel > Motor/Brake Operator
Panel XYZ)
• D4 - USB (BEP > Operator Panel) (2 used)
1Y
2. Cable, USB Operator Panel-Bulkhead 5248610
Cable G
USB (short cable inside the UI)
(J24 - P7), (J25 - P8)
2Y
3.
Gel Warmer Power 5245462
Cable AA
1Y
OP PANEL
REG
R
EG
UPPER OP
BULKHEAD
BOARD
48V
USB
AUDIO
KEYBOARD
USB
ON/
CN4
CN7
CN10
J12
J26
ENABLE
VPD
OFF
USB
UP/DN/
LOCK
BUTTONS
BUTTONS, LIGHTS
ROTARIES, SLIDES
BULKHEAD
PLATE
MEMORY STICK
MICROPHONE
J7
J5
3.3V
12V
12V
5V
+48V
P8
P1
P3
P4
J22
J21
J25
J23
J18
J3
J4
J17
P5
P6
J52
J51
J53
10.4"
SVGA
LED
BKLight
LOWER OP
USB
HUB
(2)
USB
HUB
(3)
TRACK
BALL
USB
HUB
(7)
uP
REG
5V
3.3V
PCAP
TOUCH
TOUCH
CNTRL
BKLT
CNTRL
VIDEO
CNTRL
VPD
MAIN CABLE
DVI VIDEO
48V POWER/AUDIO
USB for OP PANEL
USB for VIDEO on TOUCH PANEL
UP/DN/BRAKE/RELEASE SWITCHES
L
R
OP PANEL J24/J25
BULKHEAD P7/P8
5248610 REV

GE LOGIQ E9 Specifications

General

Type	Ultrasound System
3D/4D Imaging	Yes
Transducer Ports	4 active ports
Connectivity	DICOM, USB, Ethernet
Applications	Abdominal, Vascular, Musculoskeletal, Small Parts, Urology, Pediatric, Cardiac, Obstetrics/Gynecology
Transducers	Linear, Convex, Phased Array, Volume
Doppler Modes	Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Elastography	Yes
Advanced Features	B-Flow, Volume Navigation
Portability	Cart-based system
Display	19-inch high-resolution LCD monitor
