Replacement Procedures
7-6 LOGIQ V2/LOGIQ V1 – Basic Service Manual
5610739-100 English Rev.10
Tools needed for servicing LOGIQ V2/LOGIQ V1
NOTE: Please use the correct Screwdrivers listed in Table 7-1
Table 7-1: Standard tools list for LOGIQ V2/LOGIQ V1
No
Part
Name
Part No. QTY Screw Description Screwdriver Description
1 screw 2159632 2 Screw BH M4x6 Common Phillips Screwdriver
2 screw 2159634 4 Screw BH M4x10 WHT Common Phillips Screwdriver
3 screw 2327793 135 D2 Screw SJ2836-87
M3x8
Common Phillips Screwdriver
4 screw 2373562 3 Screw M4x10 Common Phillips Screwdriver
5 screw 5138465 10 Screw FH M2.5x5(NL) Common Phillips Screwdriver
6 screw 5176890 6 Screw DIN965A M4x8 Small Phillips Screwdriver
7 screw 5244775 2 Screw GB T820-2000
M3x8
Common Phillips Screwdriver
8 screw 5342274 4 Inch SScrew #6-32UNC Common Phillips Screwdriver
9 screw 5439265 246 Screw-M4x10 Common Phillips Screwdriver
10 screw 5445720 12 GB 818-2000 M4x30 Common Phillips Screwdriver
11 screw 2337572 2 Screw FH M3x6 Common Phillips Screwdriver
12 screw 5476381 20 Bolt M8x18 with Washer 6# Inner Hexangular Set
13 screw 5476387 34 Bolt M6x15 with Washer 5# Inner Hexangular Set
14 screw 5476394 5 Bolt M8x30 6# Inner Hexangular Set
15 screw 5476438 14 Bolt M8x36 With Washer 6# Inner Hexangular Set
16 screw 5476440 17 Bolt M6x24 With Washer 5# Inner Hexangular Set
17 screw 5477579 2 Screw_DIN912 M6_20 5# Inner Hexangular Set
18 screw 5490719 4 Screw PM SW4x8 Common Phillips Screwdriver
19 screw 5491747 1 Screw Pan Head M4x4 Common Phillips Screwdriver
20 screw 5491847 2 Hand Screw M2p5x5 by hand
To Next Page
