System Setup
3-14 LOGIQ V2/LOGIQ V1 – Basic Service Manual
5610739-100 English Rev.10
Completing the setup
Purpose of this section
This section describes how to complete the installation of
LOGIQ V2/LOGIQ V1.
Contents in this section
• ‘System specifications’ on page 3-14
• ‘Electrical specifications’ on page 3-15
• ‘Peripheral/Accessories Connector Panel’ on page 3-16
• ‘Connecting probes’ on page 3-17
• ‘Powering the system’ on page 3-17
System specifications
System requirements verification
• Verify that the site meets the requirements listed in
Chapter 2.
(See: ‘Facility needs’ on page 2-12.)
• Verify that the specifications below don’t conflict with any
on-site conditions.
Physical dimensions
Console Weight
• Weight: approx. 6 kg (13.23 lbs)
Table 3-2: Physical dimensions of LOGIQ V2/LOGIQ V1
Height Length Width Unit
120 396 368
mm
4.72 15.59 14.49
Inches

GE LOGIQ V1 Specifications

General

Brand	GE
Model	LOGIQ V1
Category	Medical Equipment
Language	English
