Replacement Procedures
7-12
LOGIQ V2/LOGIQ V1 – Basic Service Manual
5610739-100 En
glish Rev.10
Printer Shelf (5727506)
(continued)
Removal Procedure
Mounting Procedure
1.
Install the new p
arts in the reverse orde
r of removal.
T
able
7-4:
Removal Procedure for Printer Shelf
No.
Steps
Correspondi
ng Graphic
1.
Remove the screw pad.
2.
Unscrew the 2 screws.
3.
Hold the printer shelf with two hands
and push it up. Then remove the printer
shelf from the Upper Column.
201
203
