MDS 05-3438A01, Rev. F MDS 4790/9790 Series I/O Guide 37
6.3 Detailed Command Descriptions
This section gives more detailed information for most commands listed
in the previous tables. The commands are cross-referenced to descrip-
tions of corresponding commands entered using the front panel display
and control buttons (see radio graphic at left).
Alarm Summary ALARM
The ALARM and STAT commands report on current alarms. ALARM pro-
vides alarm information in a concise, two-line format. Alarm codes are
summarized in hexadecimal format. STAT (described on Page 56)
includes a text message describing each alarm.
The first line of the response to the ALARM command is a simple message
indicating whether or not alarms are present. The second line is a hexa-
decimal numeric code representing the system alarm state. Examples of
responses are:
SREV
Details, page 55
Software Revision
Details, page 78
Display software revision information
UNIT [10000–65000]
Details, page 59
Unit Diagnostic
Address
Details, page 59
Display the radio’s unit address
Table 9. PC Commands—
Owner and Radio Information (Continued)
PC COMMAND
FRONT PANEL
MENU
DESCRIPTION
A
B
Data Buffering
screen, Page 74
This graphic points you to the
corresponding front panel
menu
NO ALARMS PRESENT
CODE: 0000 0000
MINOR ALARMS PRESENT
CODE: xxxx xxxx
MAJOR ALARMS PRESENT
CODE: xxxx xxxx
Active Radio Status screen,
Page 77
A
B
To Next Page
