Set Time Use this screen to set or show the time set in the radio. The accuracy of the date
and time are important, because events are logged with the date and time.
To change the time, press ENTER, then use the left/right arrow buttons to select
the hour, minute, second, or AM/PM. Then use the up/down arrow buttons to
increase or decrease the digit, or toggle between AM and PM. Repeat for other
characters if necessary. Press ENTER again to make the change.
Set Date Use this screen to set or show the date set in the radio. The accuracy of the date
and time are important because events are logged with the date and time.
To change the date, press ENTER, then use the left/right arrow buttons to select
the month, day, or year. Then use the up/down arrow buttons to increase or
decrease the day or year, or set the month. Repeat for other characters if
necessary. Press ENTER again to make the change.
GROUP 3—DIAGNOSTICS
Operating Status This screen displays three key operating conditions of the radio: TX key status,
Received Signal Strength Indication (RSSI), and Signal-to-Noise (S/N) ratio. Unlike
other screens, the information shown on the Operating Status screen is preserved
across power outages and radio switchovers. This screen has no timeout and will
show until changed by an operator.
Active Radio
Status
Use this screen to show alarm conditions, if any. Major and minor alarm events are
listed in Table 13 on Page 57.
If there have been alarm events, press ENTER to show the first alarm. To scroll
through the list of alarms, press the right or down arrow button. Pressing
ESCAPE returns the radio to the Active Radio Status screen.
Receive Signal
Strength
This screen displays the received signal strength in dBm.
In a typical master station configuration, the received signal strength is read from
each remote radio that transmits to the master station.
Set Time
12:04:03 AM
May 01 1999
TIME [hh:mm:ss] command,
Page 57
Set Date
12:04:03 AM
May 01 1999
DATE [mmm dd yyyy]
command, Page 44
Operating Status
TX: dekeyed
RSSI: -60 dBm
S/N 10 dB
Active Radio Status
Alarms present
(enter for details)
Event: 20 (MINOR)
Configuration error
STAT command, Page 56
Rx Signal Strength
-120 dBm
RSSI, RSSI! command,
Page 52
