1–2 MULTILINK ML3000 ETHERNET COMMUNICATIONS SWITCH – INSTRUCTION MANUAL
INTRODUCTION CHAPTER 1: INTRODUCTION
1.2 Ordering
1.2.1 Order Codes
The following table lists the order codes for the Multilink Ethernet Switch (ML3000). The
fiber optic LC ports are limited to a total of 12.
Table 1–1: ML3000 Order Code Table
ML3000 Slot Mod Description
Gb 100 Mb
1 2 3 4 5 6 7 8 9 10
Base ML3K ML3000 Chassis with Fixed Power Supplies
Mounting F | | | | | | | | | | Front Mounted Ports
B | | | | | | | | | | Rear Mounted Ports
Power Supply HX|||||||||| Single Integrated 90 to 250V AC/DC Power Supply
HH|||||||||| Dual Integrated 90 to 250V AC/DC Power Supplies
LX|||||||||| Single Integrated 22 to 60V DC Power Supply
LL|||||||||| Dual Integrated 22 to 60V DC Power Supplies
P1|||||||||| Single Integrated 22 to 60V DC Power Supply with PoE Support
P2|||||||||| Dual Integrated 22 to 60V DC Power Supply with PoE Support
HL|||||||||| Combination of a 90 to 250V AC/DC and a 22 to 60V DC Power Supply
Modules A A | | | | | | | | 2 x 1000 Mbits RJ-45 Fixed Ports
B B | | | | | | | | 2 x 1000 Mbit SFP, LC Connector, mm Fiber, 550m
C C | | | | | | | | 2 x 1000 Mbit SFP, LC Connector, sm Fiber, 2km
D D | | | | | | | | 2 x 1000 Mbit SFP, LC Connector, sm Fiber, 10km
E E | | | | | | | | 2 x 1000 Mbit SFP, LC Connector, sm Fiber, 25km
F F | | | | | | | | 2 x 1000 Mbit SFP, LC Connector, sm Fiber, 40km
G G | | | | | | | | 2 x 1000 Mbit SFP, LC Connector, sm Fiber, 70km
H H | | | | | | | | 2 x 1000 Mbit SFP ports (no transceivers) empty cage
J J | | | | | | | | 2 x 1000 Mbit RJ-45 Fixed Ports with 1588 timing
K K | | | | | | | | 2 x 1000 Mbit SFP, LC Connector, mm Fiber, 550m with 1588 timing
L L | | | | | | | | 2 x 1000 Mbit SFP, LC Connector, sm Fiber, 2km with 1588 timing
M M | | | | | | | | 2 x 1000 Mbit SFP, LC Connector, sm Fiber, 10km with 1588 timing
N N | | | | | | | | 2 x 1000 Mbit SFP, LC Connector, sm Fiber, 25km with 1588 timing
P P | | | | | | | | 2 x 1000 Mbit SFP, LC Connector, sm Fiber, 40km with 1588 timing
Q Q | | | | | | | | 2 x 1000 Mbit SFP, LC Connector, sm Fiber, 70km with 1588 timing
R R | | | | | | | | 2 x 1000 Mbit SFP ports (no transceivers) empty cage with 1588 timing
X X | | | | | | | | None
A A A A A A A A 4 x 10/100Mbit - RJ45 Copper
B B B B B B B B 4 x 10/100Mbit - RJ45 Copper with PoE*
C C C C C C C C 4 x 10/100Mbit - RJ45 Copper with PoE+*
D D D D D D D D 2 x 10Mbit - ST
E E E E E E E E 2 x 100Mbit - ST mm Fiber
F F F F F F F F 2 x 100Mbit - SC mm Fiber
G G G G G G G G 4 x 100Mbit - LC mm Fiber
