CHAPTER 10: VLAN VLAN
MULTILINK ML3000 ETHERNET COMMUNICATIONS SWITCH – INSTRUCTION MANUAL 10–13
Converting Port VLAN to Tag VLAN (continued)
ML3000# show vlan type=tag
VLAN ID : 1
Name : Default VLAN
Status : Active
==============================
PORT | MODE | STATUS
==============================
9 | UNTAGGED | UP
10 | UNTAGGED | DOWN
11 | UNTAGGED | DOWN
12 | UNTAGGED | DOWN
13 | UNTAGGED | UP
14 | UNTAGGED | DOWN
15 | UNTAGGED | DOWN
16 | UNTAGGED | DOWN
ML3000# vlan type=tag
ML3000(tag-vlan)## add id=10 name=mkt port=14-16
Tag based vlan Added Successfully.
VLAN ID : 10
VLAN Name : mkt
Ports : 14-16
ML3000(tag-vlan)## edit id=10 name=engineering port=14-16
Tag based vlan Added Successfully.
VLAN ID : 10
VLAN Name : engineering
Ports : 14-16
ML3000(tag-vlan)## add id=20 name=sales port=14-16
Tag based vlan Added Successfully.
VLAN ID : 20
VLAN Name : sales
Ports : 14-16
ML3000(tag-vlan)## add id=20 name=marketing port=14-16
ERROR: Duplicate Vlan Id
ML3000(tag-vlan)## add id=30 name=marketing port=14-16
Tag based vlan Added Successfully.
VLAN ID : 30
VLAN Name : marketing
Ports : 14-16
(continued on next page)
Note that ports 14 to 16 are “DOWN” - the
VLAN configuration is preferably done
before devices are plugged in to avoid
connectivity repercussions.
Intentionally executed to
show the effect of adding a
duplicate VLAN.
