CHAPTER 10: VLAN VLAN
MULTILINK ML3000 ETHERNET COMMUNICATIONS SWITCH – INSTRUCTION MANUAL 10–15
Converting Port VLAN to Tag VLAN (continued)
ML3000(tag-vlan)## set-port port=14-16 filter status=enable
WARNING: PVID does not match the port(15)'s VLAN ID(s).
If you are using telnet session on this port,setting ingress might stop the session.
Do you want to continue? ['Y' or 'N'] Y
WARNING: PVID does not match the port(14)'s VLAN ID(s).
If you are using telnet session on this port, setting ingress might stop the session.
Do you want to continue? ['Y' or 'N'] Y
WARNING: PVID does not match the port(16)'s VLAN ID(s).
If you are using telnet session on this port, setting ingress might stop the session.
Do you want to continue? ['Y' or 'N'] Y
Ingress Filter Enabled
ML3000(tag-vlan)## show vlan type=tag
VLAN ID : 1
Name : Default VLAN
Status : Active
==============================
PORT | MODE | STATUS
==============================
9 | UNTAGGED | UP
10 | UNTAGGED | DOWN
11 | UNTAGGED | DOWN
12 | UNTAGGED | DOWN
13 | UNTAGGED | UP
VLAN ID : 10
Name : engineering
Status : Active
==============================
PORT | MODE | STATUS
==============================
14 | UNTAGGED | DOWN
15 | UNTAGGED | DOWN
16 | UNTAGGED | DOWN
VLAN ID : 20
Name : sales
Status : Active
==============================
PORT | MODE | STATUS
==============================
14 | UNTAGGED | DOWN
15 | UNTAGGED | DOWN
16 | UNTAGGED | DOWN
VLAN ID : 30
Name : marketing
Status : Active
==============================
PORT | MODE | STATUS
==============================
Enable filtering on the ports required. The
software will prompt to ensure that
connectivity is not disrupted.
VLANs are now active. However, as the
packet traverses VLANs, the packet should
be tagged. This is enabled next.
