13–10 MULTILINK ML3000 ETHERNET COMMUNICATIONS SWITCH – INSTRUCTION MANUAL
RAPID SPANNING TREE PROTOCOL CHAPTER 13: RAPID SPANNING TREE PROTOCOL
Example 13-4: Configuring RSTP
ML3000# rstp
ML3000(rstp)## show stp config
RSTP CONFIGURATION
------------------
Rapid STP/STP Enabled(Global) : NO
ML3000(rstp)## show active-stp
Current Active Mode: RSTP.
RSTP is Disabled.
ML3000(rstp)## rstp enable
Successfully set the RSTP status
ML3000(rstp)## show active-stp
Current Active Mode: RSTP.
RSTP is Enabled.
ML3000(rstp)## show stp config
RSTP CONFIGURATION
-----------------
Rapid STP/STP Enabled(Global) : YES
RSTP/STP Enabled Ports : 9,10,11,12,13,14,15,16
Protocol : Normal RSTP
Bridge ID : 80:00:00:20:06:25:ed:89
Bridge Priority : 0
Bridge Forward Delay : 15
Bridge Hello Time : 02
Bridge Max Age : 20
Root Port : 0
Root Path Cost : 0
Designated Root : 80:00:00:20:06:25:ed:89
Designated Root Priority : 0
Root Bridge Forward Delay : 15
Root Bridge Hello Time : 02
Root Bridge Max Age : 20
Topology Change Count : 0
Time Since Topology Chg : 33
ML3000(rstp)## show stp ports
RSTP Port Configuration
--------------------------------------------------------------------------------------
Port# Type Priority Path Cost State Des. Bridge Des. Port
--------------------------------------------------------------------------------------
09 TP(10/100) 128 2000000 Forwarding 80:00:00:20:06:25:ed:89 00:09
10 TP(10/100) 128 2000000 Disabled 00:0a
11 TP(10/100) 128 2000000 Disabled 00:0b
12 TP(10/100) 128 2000000 Disabled 00:0c
13 TP(10/100) 128 200000 Forwarding 80:00:00:20:06:25:ed:89 00:0d
14 TP(10/100) 128 2000000 Disabled 00:0e
15 TP(10/100) 128 2000000 Disabled 00:0f
16 TP(10/100) 128 2000000 Disabled 00:10
ML3000(rstp)## forceversion rstp
Error: Force Version already set to Normal RSTP
Check the status of STP or RSTP. These
commands show if STP or RSTP is
enabled.
