CHAPTER 19: MODBUS PROTOCOL MODBUS PROTOCOL
MULTILINK ML3000 ETHERNET COMMUNICATIONS SWITCH – INSTRUCTION MANUAL 19–7
00BE Port 9 activity 0 to 1 1 F3 0
00BF Port 10 activity 0 to 1 1 F3 0
00C0 Port 11 activity 0 to 1 1 F3 0
00C1 Port 12 activity 0 to 1 1 F3 0
00C2 Port 13 activity 0 to 1 1 F3 0
00C3 Port 14 activity 0 to 1 1 F3 0
00C4 Port 15 activity 0 to 1 1 F3 0
00C5 Port 16 activity 0 to 1 1 F3 0
00C6 Port 17 activity 0 to 1 1 F3 0
00C7 Port 18 activity 0 to 1 1 F3 0
00C8 Port 19 activity 0 to 1 1 F3 0
00C9 Port 20 activity 0 to 1 1 F3 0
00CA Port 21 activity 0 to 1 1 F3 0
00CB Port 22 activity 0 to 1 1 F3 0
00CC Port 23 activity 0 to 1 1 F3 0
00CD Port 24 activity 0 to 1 1 F3 0
00CE Port 25 activity 0 to 1 1 F3 0
00CF Port 26 activity 0 to 1 1 F3 0
00D0 Port 27 activity 0 to 1 1 F3 0
00D1 Port 28 activity 0 to 1 1 F3 0
00D2 Port 29 activity 0 to 1 1 F3 0
00D3 Port 30 activity 0 to 1 1 F3 0
00D4 Port 31 activity 0 to 1 1 F3 0
00D5 Port 32 activity 0 to 1 1 F3 0
00D6 Port 1: Number of bytes received 0 to
4294967295
1F9 0
00D8 Port 1: Number of bytes sent 0 to
4294967295
1F9 0
00DA Port 1: Number of frames received 0 to
4294967295
1F9 0
00DC Port 1: Number of frames sent 0 to
4294967295
1F9 0
00DE Port 1: Total bytes received 0 to
4294967295
1F9 0
00E0 Port 1: Total frames received 0 to
4294967295
1F9 0
00E2 Port 1: Number of broadcast frames
received
0 to
4294967295
1F9 0
00E4 Port 1: Number of multicast frames
received
0 to
4294967295
1F9 0
00E6 Port 1: Number of frames with CRC
error
0 to
4294967295
1F9 0
00E8 Port 1: Number of oversized frames
received
0 to
4294967295
1F9 0
00EA Port 1: Number of bad fragments
received (<64 bytes)
0 to
4294967295
1F9 0
00EC Port 1: Number of jabber frames
received
0 to
4294967295
1F9 0
00EE Port 1: Number of collisions occurred 0 to
4294967295
1F9 0
Table 19–1: Modbus memory map (Sheet 4 of 33)
Address Description Range Step Format Default
