Programming the VGA Optica 4-11
January 2006
Data Fields
Buzzer/Sound
Table 4-7: Data Field Options
Item Function Available Options
Field
Graph line number and numeric display number to
be programmed
1, 2, 3, 4, 5 or 6
Parameter
For the field selected above, choose which
parameter will be output.
Humidity, Temperature,
Pressure or User Equation
Units
Choose the units for this parameter See Table 4-1 on page 4-4 for
the parameter chosen.
GrphMax
Set the parameter value that will produce full-scale
on the graph.
(enter a number)
GrphMin
Set the parameter value that will produce zero on the
graph.
(Enter a number.)
GrphColor
Set the color for the selected graph line. Black, Red, Green, Orange,
Blue, Violet, Yellow or Brown
Decimals
The number of decimal places for the numeric dis-
play
Enter a number (6 maximum).
Table 4-8: Buzzer/Sound Option
Item Function Available Options
Buzzer/Sound Sets the length (apparent loudness) of keyclick
sounds.
Enter length of keyclick sound
in msec (150 msec maximum).
