Appendix B. Modbus Communication
38 PanaFlow™ XMT1000 User’s Manual
706 N/A eSystem_
Admin
Password
Admin user password unitless RO 4 INT32
708 N/A eSystem_MCU
_Bootloader_
version
MCU bootloader version unitless RO 4 INT32
70A N/A eSystem_MCU
_Software_
Ver sio n
MCU Software version unitless RO 4 INT32
70C N/A eSystem_COM
_Software
_Version
COM Option Software
version
unitless RO 4 INT32
70E N/A eSystem_OPT_
Software_
Ver sio n
IO Option Software
version
unitless RO 4 INT32
710 N/A Reserved Reserved unitless RO 4 INT32
712 N/A eSystem_MCU
_Flash_CRC
MCU flash CRC unitless RO 4 INT32
740 740 N/A eSystem_
ErrMaster
master error unitless RO 4 INT32
742 N/A eSystem_
MCU_Err
MCU error unitless RO 4 INT32
744 N/A eSystem_OPT_
Err
Option Board error unitless RO 4 INT32
746 N/A eSystem_MCU
_Startup_Err
MCU startup error unitless RO 4 INT32
748 N/A eSystem_OPT_
Startup_Err
Option startup error unitless RO 4 INT32
74A N/A eSystem_
Comm_Err
comm error unitless RO 4 INT32
74C N/A eSystem_
Comm_
TryNum
comm try times unitless RO 4 INT32
74E N/A eSystem_
Comm_
FailNum
comm fail times unitless RO 4 INT32
750 N/A eSystem_
Comm_
WrongNum
comm data wrong times unitless RO 4 INT32
752 N/A eSystem_Cmd_
State
System command state unitless RO 4 INT32
System Real RO
Display Real RW
800
Table 6: XMT1000 Modbus Register Map - Revision 4.19 (cont.)
Reg #
in Hex
Access
Level
Register ID Description Units RO/RW
Size in
Bytes
Format
