PanaFlow™ XMT1000 User’s Manual 39
Appendix B. Modbus Communication
Display Int RW
900 900 Operator eDisplay_
Language
Display Language unitless RW 4 INT32
902 Viewer eDisplay_Var1_
Va l ue
Display Variable_1
Register Address
unitless RW 4 INT32
904 Viewer eDisplay_Var1_
Unit
Display Variable_1 Unit
Code Address
unitless RW 4 INT32
906 Viewer eDisplay_Var2_
Va l ue
Display Variable_2
Register Address
unitless RW 4 INT32
908 Viewer eDisplay_Var2_
Unit
Display Variable_2 Unit
Code Address
unitless RW 4 INT32
90A Viewer eDisplay_Tot1_
Va l ue
Display Totalizer_1
Register Address
unitless RW 4 INT32
90C Viewer eDisplay_Tot1_
Unit
Display Totalizer_1 Unit
Code Address
unitless RW 4 INT32
90E Viewer eDisplay_Tot2_
Va l ue
Display Totalizer_2
Register Address
unitless RW 4 INT32
910 Viewer eDisplay_
Tot2_Unit
Display Totalizer_2 Unit
Code Address
unitless RW 4 INT32
912 Viewer eDisplay_
Graph_Value
Display Graph_1 Register
Address
unitless RW 4 INT32
914 Viewer eDisplay_
Graph_Unit
Display Graph_1 Unit
Code Address
unitless RW 4 INT32
916 Operator eDisplay_
Select_Vel
select the velocity unitless RW 4 INT32
918 Operator eDisplay_
Select_ActVol
select the Actual
Volumetric
unitless RW 4 INT32
91A Operator eDisplay_
Select_StdVol
select the Standardized
Volumetric
unitless RW 4 INT32
91C Operator eDisplay_
Select_Mass
select Mass unitless RW 4 INT32
91E Operator eDisplay_
Select_Tot
select Totalizer unitless RW 4 INT32
920 Operator eDisplay_
Select_Dens
select Density unitless RW 4 INT32
922 Viewer eDisplay_
Select_Decimal
_1ST
Select 1st Display
Decimal
unitless RW 4 INT32
924 Viewer eDisplay_Type Type of DISPLAY unitless RW 4 INT32
926 Operator eDisplay_
Timeout
TimeOut for DISPLAY 13 RW 4 INT32
928 Operator eDisplay_
BackLight
BackLight Control unitless RW 4 INT32
92A Viewer eDisplay_
MenuLock
Lock menu unitless RW 4 INT32
92C Operator eDisplay_Unit
Type_Vel
Unit type for velocity unitless RW 4 INT32
Table 6: XMT1000 Modbus Register Map - Revision 4.19 (cont.)
Reg #
in Hex
Access
Level
Register ID Description Units RO/RW
Size in
Bytes
Format
