Appendix D. Foundation Fieldbus Communication
66 PanaFlow™ XMT1000 User’s Manual
D.4.3 NAMUR NE107 (cont.)
The NAMUR NE107 Errors and their Default Categories in the XMT1000 Resource Block are listed in Table 7 below.
Table 7: NAMUR NE107 Errors and XMT1000 Default Categories
Error Sub-Error Description Default Category
CRC Configuration Error Persistent Parameter CRC Fault Failed
Software Failure Stack Overflow failure Failed
Sequence or Windowed Watch Dog failure Failed
Software fault Failed
Device Initialization Failure Initialization failed Failed
Hardware Failure ADC Bit Test Fault Failed
VGA test Fault Failed
Clock Frequency Fault Failed
CPU test Fault Failed
Invariable Flash Memory Fault Failed
Variable Memory Fault Failed
FPGA Configuration CRC fault Failed
Temperature Test Fault Failed
Driver Failure Failed
Watch Dog failure Failed
DSP Hardware Errors Failed
Default ISR (DSP Exception) Failed
DSP Exception Failed
Modbus Communication Loss No Modbus communication Failed
Sensor Value out of Range VelocityWarning Offspec
Device not calibrated NotCalibrated Offspec
Sensor Measurement Error SingleChAccuracy Offspec
MultiChAccuracy Offspec
ActiveTw Offspec
CycleSkip Offspec
Amplitude Offspec
SignalQuality Offspec
VelocityRange Offspec
SoundSpeed Offspec
SNR Offspec
Device in Configuration Mode In Configuration Mode - Indication Check
Unsupported Parameter Warning Unsupported Parameter - Warning Check
Invalid Parameter Range Warning Invalid Parameter Range - Warning Check
Invalid Request Warning Invalid request - Warning Check
Invalid User Warning Invalid User - Warning Check
