6.1.2 Actual Values Menu
 ACTUAL VALUES [Z]
A1 METERING
 CURRENT [Z]
See page 6–4.
MESSAGE

VOLTAGE [Z]
See page 6–6.
MESSAGE

PHASORS [Z]
See page 6–8.
MESSAGE

POWER [Z]
See page 6–8.
MESSAGE

ENERGY [Z]
See page 6–12.
MESSAGE

DEMAND [Z]
See page 6–14.
MESSAGE

FREQUENCY [Z]
See page 6–15.
MESSAGE

PULSE INPUT [Z]
COUNTERS
See page 6–16.
MESSAGE

ANALOG INPUT [Z]
See page 6–17.
MESSAGE

END OF PAGE A1 [Z]
MESSAGE

ACTUAL VALUES [Z]
A2 STATUS
 ALARMS [Z]
See page 6–18.
MESSAGE

SWITCHES [Z]
See page 6–20.
MESSAGE

CLOCK [Z]
See page 6–21.
MESSAGE

PROGRAMMABLE [Z]
MESSAGE
See page 6–21.
MESSAGE

END OF PAGE A2 [Z]
MESSAGE

ACTUAL VALUES [Z]
A3 POWER ANALYSIS
 POWER QUALITY [Z]
VALUES
See page 6–22.
MESSAGE

TOTAL HARMONIC [Z]
DISTORTION
See page 6–22.
MESSAGE

DATA LOGGER [Z]
See page 6–24.
