GE Reason RT430 User Manual

GPS Grandmaster Clock
24
RT430-TM-EN-5
1.6.7 Open Collector Electrical Outputs
TABLE 9: Open callector outputs specifications.
Maximum collector emetter voltage
400 V
Maximum current
200 mA
1.6.8 Optical Outputs
TABLE 10: Optical outputs specifications.
Connector
ST
Weve-length
820 nm
Fiber Type
Multimodo 50 / 125 µm, 100 / 140 µm ou 200 µm HCS
Emission power
- 17.8 dBm (50 / 125 µm)
- 14.0 dBm (62.5 / 125 µm)
- 8.5 dBm (100 / 140 µm
- 5.7 dBm (200 µm HCS)
Length of optical fiber cables should not exceed 2 Km
1.6.9 Amplitude Modulated Outputs
TABLE 11: Amplitude modulated outpus specifications.
Signal
IRIG-B124
Connector
BNC (female)
Empty Amplitude
4 Vpp
50 Ω Amplitude
3 Vpp
Relative level High/Low
3.3
Carrier Frequency
1 kHz
