User Manual TLE Series 600 & 800 CE S1
Code
Alarm
Description
4146
4TH LEG DRIVER FAILURE
The Booster’s driver indicates the presence of a
defect which switches the power off.
4147
BATTERY CHARGER DRIVER FAILURE
The Battery charger driver indicates a defect,
switching it off.
4150
BOOSTER OVERTEMPERATURE
The temperature of the booster bridge exceeds
the machine’s set limit or the coil’s sensor is on.
4151
4TH LEG OVERTEMPERATURE
The temperature of the 4
th
leg’s bridge exceeds
the machine’s set limit.
4301
INVERTER FUSES
The alarm signals an inverter outlet fuses fault,
causing it to switch off immediately.
It may only be manually switched on after the
alarm has ceased.
4304
K7 CLOSING FAILURE
K7 not closed despite a closing command.
Signalled by auxiliary contact.
Load will be supplied by Mains.
4305
K7 OPENING FAILURE
K7 not open despite an opening command.
Signalled by auxiliary contact.
Load will be supplied by Mains.
4307
INVERTER TRANSFORMER
OVERTEMPERATURE
The temperature sensor of the Inverter
Transformer indicates overtemperature.
Elapsed “stop operation” time, Inverter shut-
down.
With Mains OK, Load is transferred on Mains.
4308
DC FUSES FAILURE
Blown input DC fuse(s) F1 of the Inverter.
Inverter cannot be started as long as present.
4309
DRIVER FAILURE
An abnormal condition has been detected on one
or more power modules of the Inverter
(temperature or overcurrent).
Inverter shut-down and cannot be started as
long as the alarm is present.
4310
IGBT RECTIFIER DRIVER FAILURE
Indicates a failure on the driver board or the
Rectifier IGBT bridge.
The Rectifier is shut-down.
4311
BOOSTER DRIVER FAILURE
Driver Booster error signal.
4312
INVERTER VOLTAGE OUT
OF TOLERANCE
Inverter Output Voltage is out of the tolerances (
10%).
Inverter is switched OFF.
4320
ISMAX DETECTION
Detection of Inverter Bridge (Is) current limit
causing the Inverter OFF and automatic re-start.
After 3 times the Inverter switches-Off, and it can
be restarted manually.
4321
HIGH CURRENT SHARING
A high exchange current value is detected
between the UPS of the Parallel System.
4340
INVERTER CONTROL FAILURE
The “Slave” oscillator is not in synchronized with
the Master; thus causing the shut-down of its
Inverter.
If after a restart the condition remains, the LED
inside the Inverter symbol on the panel will not
light up, indicating that this Inverter cannot
supply the Load anymore.
