User Manual TLE Series 600 & 800 CE S1
Code
Alarm
Description
4571
OVERLOAD: LOAD ON MAINS
With Mains Bypass supply available and Load
115%, the Load is transferred on Mains.
Load will be transferred again automatically on
Inverter when Load 100%.
4581
INVERTER AND MAINS
NOT SYNCHRONIZED
The voltages of Mains and Inverter are not
synchronized, which causes the opening of K6.
4608
ECO CONFIG FAILURE
The propagation of the eBoost / IEMi
configuration to other units in a Parallel System
failed.
4697
BATTERY OVERTEMPERATURE
Detection of Battery overtemperature condition.
Only a GE Service Engineer can reset the alarm.
4698
BATTERY POWER INSUFFICIENT
In case of Mains Failure, with the actual Load, the
run time would be below stop operation time
(default 3 minutes).
4700
DC LOW
Battery voltage is at the lowest limit.
Inverter will remain Off until the battery voltage
reaches the value in parameter.
4701
POWER SUPPLY BOARD FAILURE
Detection of a failure on the Power Supply Board,
in particular from the DC supply.
Can be enabled or disabled with respective
parameter.
4702
LOSS OF REDUNDANCY
A time of lost redundancy superior than specified
in respective parameter was detected.
4900
LOAD LOCKED ON INVERTER
The Load is locked on Inverter after 3 Load
transfers within 30 seconds.
After time out (default 30 sec.) Bypass will be free.
4955
OVERTEMPERATURE
An overtemperature condition has been detected
on Inverter.
Elapsed “stop operation” time, Inverter shut-
down.
With Mains OK, Load is transferred on Mains.
4998
LOAD OFF DUE TO EXTENDED
OVERLOAD
Load Off after time-out of “stop operation” for
overload on Inverter (time depending on the % of
overload).
4999
LOAD OFF DUE TO LOW BATT. OR TEMP.
Load Off after time-out of “stop operation” with
missing Mains due to Battery low voltage or
overtemperature condition.
