Item Designation Material DN 15 DN 20 DN 25 DN 40 DN 50
Butterfly valve
T-smart 711 (SS) cpl.
304 / EPDM 224-905.20 224-905.21 224-905.22 224-905.24 224-905.25
316L / EPDM 224-905.01 224-905.02 224-905.03 224-905.05 224-905.06
304 / FKM 224-915.20 224-915.21 224-915.22 224-915.24 224-915.25
316L / FKM 224-915.01 224-915.02 224-915.03 224-915.05 224-915.06
304 / HNBR 224-925.20 224-925.21 224-925.22 224-925.24 224-925.25
316L / HNBR 224-925.01 224-925.02 224-925.03 224-925.05 224-925.06
304 / VMQ 224-935.20 224-935.21 224-935.22 224-935.24 224-935.25
316L / VMQ 224-935.01 224-935.02 224-935.03 224-935.05 224-935.06
Sealing set SS cpl. EPDM 224-001332 224-001332 224-001300 224-001304 224-001308
FKM 224-001333 224-001333 224-001301 224-001305 224-001309
HNBR 224-001334 224-001334 224-001302 224-001306 224-001310
VMQ 224-001335 224-001335 224-001303 224-001307 224-001311
1 Flap 304 224-001007 224-001007 224-000999 224-001000 224-001001
316L 224-000810 224-000810 224-000802 224-000803 224-000804
2 Seal EPDM 224-170.61 224-170.61 224-170.67 224-170.68 224-170.69
FKM 224-170.75 224-170.75 224-170.81 224-170.82 224-170.83
HNBR 224-170.89 224-170.89 224-170.95 224-170.96 224-170.97
VMQ 224-173.05 224-173.05 224-173.11 224-173.12 224-173.13
3 Round plug PE 922-338 922-338 922-338 922-338 922-338
4 Cheese head screw A2-70 4x 902-099 4x 902-099 4x 902-099 4x 902-099 4x 902-100
M6 x 30 M6 x 30 M6 x 30 M6 x 30 M8 x 30
5 Hexagon nut A2 4x 910-013 4x 910-013 4x 910-013 4x 910-013 4x 910-018
M6 M6 M6 M6 M8
21 Plain bearing IGLIDUR F 704-045 704-045 704-045 704-045 704-045
A Flange see Overview of flanges
Grease RIVOLTA F.L.G. MD-2 100g tube not included in the sealing set.
Grease BARRIERTA L 55/3 (only for seals VMQ)
413-136
413-137
Items 2 and 21 are included in the sealing set 429-043
Parts list - Butterfly valve body T-smart 7
430BAL009990EN_2
62 30.01.2018
