Item Designation Material DN 65 DN 80 DN 100 DN 125 DN 150
Butterfly valve
T-smart 711 (SS) cpl.
304 / EPDM 224-905.26 224-905.27 224-905.28 224-905.29 224-905.30
316L / EPDM 224-905.07 224-905.08 224-905.09 224-905.10 224-905.11
304 / FKM 224-915.26 224-915.27 224-915.28 224-915.29 224-915.30
316L / FKM 224-915.07 224-915.08 224-915.09 224-915.10 224-915.11
304 / HNBR 224-925.26 224-925.27 224-925.28 224-925.29 224-925.30
316L / HNBR 224-925.07 224-925.08 224-925.09 224-925.10 224-925.11
304 / VMQ 224-935.26 224-935.27 224-935.28 224-935.29 224-935.30
316L / VMQ 224-935.07 224-935.08 224-935.09 224-935.10 224-935.11
Sealing set SS cpl. EPDM 224-001312 224-001316 224-001320 224-001324 224-001328
FKM 224-001313 224-001317 224-001321 224-001325 224-001329
HNBR 224-001314 224-001318 224-001322 224-001326 224-001330
VMQ 224-001315 224-001319 224-001323 224-001327 224-001331
1 Flap 304 224-001002 224-001003 224-001004 224-001005 224-001006
316L 224-000805 224-000806 224-000807 224-000808 224-000809
2 Seal EPDM 224-170.70 224-170.71 224-170.72 224-170.73 224-170.74
FKM 224-170.84 224-170.85 224-170.86 224-170.87 224-170.88
HNBR 224-170.98 224-170.99 224-170.02 224-170.03 224-170.04
VMQ 224-173.14 224-173.15 224-173.16 224-173.17 224-173.18
3 Round plug PE 922-338 922-338 922-338 922-338 922-339
4 Cheese head screw A2-70 6x 902-100 6x 902-100 6x 902-100 6x 902-119 8x 902-088
M8 x 30 M8 x 30 M8 x 30 M10 x 40 M12 x 45
5 Hexagon nut A2 6x 910-018 6x 910-018 6x 910-018 6x 910-026 8x 910-029
M8 M8 M8 M10 M12
21 Plain bearing IGLIDUR F 704-045 704-045 704-045 704-046 704-046
A Flange see Overview of flanges
Grease RIVOLTA F.L.G. MD-2 100g tube not included in the sealing set.
Grease BARRIERTA L 55/3 (only for seals VMQ)
413-136
413-137
Items 2 and 21 are included in the sealing set 429-043
Parts list - Butterfly valve body T-smart 7
430BAL009990EN_2
30.01.2018 63
