Item Designation Material 0.5" OD 0.75" OD 1" OD 1.5" OD
Butterfly valve
T-smart 711 (SS) cpl.
304 / EPDM 224-905.31 224-905.21 224-905.33 224-905.34
316L / EPDM 224-905.12 224-905.01 224-905.14 224-905.15
304 / FKM 224-915.31 224-915.20 224-915.33 224-915.34
316L / FKM 224-915.12 224-915.01 224-915.14 224-915.15
304 / HNBR 224-925.31 224-925.20 224-925.33 224-925.34
316L / HNBR 224-925.12 224-925.01 224-925.14 224-925.15
304 / VMQ 224-935.31 224-935.20 224-935.33 224-935.34
316L / VMQ 224-935.12 224-935.01 224-935.14 224-935.15
Sealing set SS cpl. EPDM 224-001332 224-001332 224-001332 224-001336
FKM 224-001333 224-001333 224-001333 224-001337
HNBR 224-001334 224-001334 224-001334 224-001338
VMQ 224-001335 224-001335 224-001335 224-001339
1 Flap 304 224-001007 224-001007 224-001007 224-001008
316L 224-000810 224-000810 224-000810 224-000811
2 Seal EPDM 224-170.61 224-170.61 224-170.61 224-170.62
FKM 224-170.75 224-170.75 224-170.75 224-170.76
HNBR 224-170.89 224-170.89 224-170.89 224-170.90
VMQ 224-173.05 224-173.05 224-173.05 224-173.06
3 Round plug PE 922-338 922-338 922-338 922-338
4 Cheese head screw A2-70 4x 902-099 4x 902-099 4x 902-099 4x 902-099
M6 x 30 M6 x 30 M6 x 30 M6 x 30
5 Hexagon nut A2 4x 910-013 4x 910-013 4x 910-013 4x 910-013
M6 M6 M6 M6
21 Plain bearing IGLIDUR F 704-045 704-045 704-045 704-045
A Flange see Overview of flanges
Grease RIVOLTA F.L.G. MD-2 100g tube not included in the sealing set.
Grease BARRIERTA L 55/3 (only for seals VMQ)
413-136
413-137
Items 2 and 21 are included in the sealing set 429-043
Parts list - Butterfly valve body T-smart 7
430BAL009990EN_2
64 30.01.2018
